As a professional high quality R&S SGT100A Signal Generators manufacturer, you can rest assured to buy it from our factory. Smallest standalone vector signal generator with integrated baseband generator.
| Product Name | Frequency range | Level range | I/Q modulation bandwidth | Harmonics |
| R&S®SGT100A | 1 MHz-6 GHz | +17 dBm - -120 dBm | 240 MHz internal 1 GHz external | < -30dBc |
Fast frequency and level switchover times
I/Q modulation bandwidth of up to 240 MHz
Excellent RF characteristics for best EVM and ACLR performance
Easy signal generation for digital standards such as 5G or WLAN
Ideal enhancement for the R&S;®SMW200A in MIMO applications
As a professional high quality R&S SGT100A Signal Generators manufacturer, you can rest assured to buy it from our factory. The R&S®SGT100A has a clear focus on automated environments with high speed and a compact design. The radio frequency chain has been optimized for the fastest frequency and level switchover times. In the baseband, the multisegment waveform mode helps users quickly switch from one test signal to the next. Though compact in size, the R&S®SGT100A has excellent RF characteristics (signal quality and level accuracy). Maximum output level, level repeatability and excellent EVM performance are key characteristics in production environments. Equipped with a LAN and USB interface, the R&S®SGT100A enables remote control of test equipment in automated applications.
Smallest standalone vector signal generator with integrated baseband generator
Fast frequency and level switchover to optimize production throughput
High output level to compensate for losses in the test system
Low power consumption for reduced heat dissipation and simplified thermal management within the system
Measured delay of 2 µs for switching between signals in multisegment waveform mode
Excellent modulation accuracy for large test margins
Outstanding frequency response due to integrated baseband generator
Excellent level repeatability and linearity for outstanding reproducibility of measurements
Optional high-performance OCXO to provide a stable and precise test system reference clock without taking up additional rack space
Optional analog I/Q outputs enabling full-featured envelope tracking test capabilities
Measured frequency response across the maximum modulation bandwidth of 240 MHz at different carrier frequencies
Low acquisition costs
Simple modular design for easy servicing
Easily upgradeable on customer premises
Waveform package as ideal production solution
Fast remote control interfaces for easy integration into test setup
Inside view of the R&S®SGT100A with modular design for easy servicing
