Buy N9926A FieldFox Handheld Microwave Spectrum Analyzer which is of high quality directly with low price. Perform accurate testing with Quick, Cal, full two-port unknown thru Cal, and Thru, Reflect, Line (TRL) calibration in the field.
Never Sacrifice Capability or Portability
N9926A FieldFox Handheld Microwave Spectrum Analyzer are equipped to handle your toughest working environments during routine maintenance, in-depth troubleshooting, and anything in between. Choose the Keysight FieldFox network analyzer configuration that best meets your needs.
Configure as a full, two-port VNA, time-domain reflectometer, vector voltmeter, cable and antenna analyzer, and more.
Measure all four S-parameters simultaneously with a single connection and up to 95 dB of dynamic range.
Perform accurate testing with QuickCal, full two-port unknown thru Cal, and Thru, Reflect, Line (TRL) calibration in the field.
Measure average and pulse power easily with a USB power sensor.
Carry the lightest handheld VNA at only 3.0 kg (6.6 lb.).
What's included:
AC/DC adapter
Localized power cord
Rechargeable Li-ion battery
Soft carrying case with backpack and shoulder straps
Quick Reference Guide
| Additional CAT/VNA Based Features: | QuickCal (Subset) |
| DTF/TDR Cable Measurements | Mixed-Mode S-Parameters |
| Vector Voltmeter | Additional SA Based Features: |
| Built-In Power Meter | Applications: |
| S-Parameters | Distance-To-Fault |
| Cable Trimming | Return Loss |
| Insertion Loss/Gain | Power Measurements |
| Best Speed at 201 Point, 1 Sweep: | 210 ms |
| Cable and Antenna Analyzer: | Yes - Optional |
| Components: | Cables |
| Antennas | Amplifiers |
| Filters | 75 Ohm CATV Devices |
| Dynamic Range: | 100 dB |
| Instrument Type: | Vector Network Analyzer |
| Maximum Frequency: | 14 GHz |
| Minimum Frequency: | 30 kHz |
| Number of Built-In Ports: | 2 ports |
| Output Power: | Up to 1 dBm |
| Spectrum Analyzer: | No |
| System Features: | GPS Receiver - Internal Only |
| Remote Control Capability | Built-In DC Source |
| Type: | Handheld |
| Trace Noise: | 0.004 dB rms |
| Vector Network Analyzer: | Yes - Standard |
