You can rest assured to buy customized M9484C VXG Vector Signal Generators from us. The M9484C VXG is the industry's first dual-channel vector signal generator capable of generating signals up to 54 GHz with 2.5 GHz of modulation bandwidth per channel.
You can rest assured to buy customized M9484C VXG Vector Signal Generators from us. Designing 5G and satellite communication systems requires tight design margins and timelines, complex modulation, and adherence to stringent standards. You're facing a whole new set of design and test challenges, including wider bandwidths, higher frequencies, and greater system complexity. The M9484C VXG provides the industry's first vector signal generator with up to 54 GHz frequency range and 2.5 GHz of modulation bandwidth in a single instrument, or up to 110 GHz with the V3080A frequency extender and 5 GHz with channel bonding, to enable your next breakthrough.
Supports MIMO real-time fading for all 3GPP 5G NR base station conformance tests with PathWave Signal Generation software
Covers all 5G NR frequency bands and V- / W-band for satellite communications
Generates complex wideband signals needed for carrier aggregation and digital pre-distortion (DPD) applications
Delivers superior RF performance for accurately characterizing devices under test, such as phase noise, error vector magnitude (EVM), and adjacent channel power ratio (ACPR)
Simplifies MIMO and beamforming test setups with up to 4 synchronized and phase-coherent channels in one instrument and more than 32 channels in multiple instruments
Streamlines complex receiver test scenarios with the world's first 8-virtual-signal emulation per RF channel
| Frequency | 9 kHz to 54 GHz |
| RF Bandwidth | Up to 2.5 GHz |
| Waveform Playback Memory | Up to 4096 MSa |
| RF Channels | 1/2/4 Channels |
| Type | Vector |
